Blue Luminescent Graphene Quantum Dots
₹0.00
| Product Number | Â NCZC3004 |
| CAS Number | 7440-40-0Â |
| Concentration | 1mg/mL to 20 mg/mL (in stock), Concentration Customization is possible |
| Carrier: | Water, Ethanol, IPA, NMP, Toluene, Methanol, Dispersion Customization is Possible |
| APS | 5-10 nm |
| Package Size | 1-100 mL ( Large Volume packs are also available) |
CHARACTERIZATIONS
| Composition: |
Graphene Quantum Dots |
| Appearance: | Colorless solution |
| PL peak: | 460 nm (reference only, the actual value may vary) |
| Particle Size: | ＜10 nm |
| Concentration: | 1 mg/ml (available up to 20mg/ml) |
| Solution: | Water, Toluene (customization possible) |
| Purity: | >99.9% |
Please Note: Graphene Quantum Dots dried Powder is also available in Hydrophilic and Hydrophobic form. Please contact us for Price and other parameters customization.
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities & Customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) are available upon request.
Shipping & Delivery
Related products
CVD Graphene on Copper Foil
CAS No.: 7782-42-5 (graphene), 7440-50-8 (copper)
PREPARATION METHOD:Â CVD Method
WAFER STRUCTURE: Graphene on Copper Foil (both sides), Copper Foil 45 µm
CHARACTERIZATION & ANALYSIS
Predominantly Single-layer Graphene on Copper Substrate
| Sheet Resistance | <600Ω/sq |
| Custom Order | <300Ω/sq |
| Transparency | >95% |
| Product Name |
CVD Graphene on Copper Foil |
| Stock No. | NCZ-GSW-0016 |
| Purity | > 99.9% |
| Graphene Film | |
| FET Electron Mobility on Al2O3 | 2000 cm2/Vs |
| Hall Electron Mobility on SiO2/Si | Â 4000 cm2/Vs |
CVD Graphene on PET Substrate
| Product Name |
CVD Graphene on PET Substrate |
| Stock No. | NCZ-GSW-0019 |
| Purity | > 99.9% |
| Graphene Film | |
| FET Electron Mobility on Al2O3 | 2000 cm2/Vs |
| Hall Electron Mobility on SiO2/Si | Â 4000 cm2/Vs |
| Sheet Resistance | <600Ω/sq |
| Custom Order | <300Ω/sq |
| Transparency | >95% |
CVD Graphene on Quartz Substrate
| Product Name |
CVD Graphene on  Quartz Substrate |
| Stock No. | NCZ-GSW-0020 |
| Purity | > 99.9% |
| Graphene Film | |
| FET Electron Mobility on Al2O3 | 2000 cm2/Vs |
| Hall Electron Mobility on SiO2/Si | Â 4000 cm2/Vs |
| Sheet Resistance | <600Ω/sq |
| Custom Order | <300Ω/sq |
| Transparency | >95% |
| CVD Graphene | Substrate |
| 1cm x 1cm | Diameter: 1inch, Thickness: 3mm* |
| 1inch x 1inch | 30mm x 30mm, Thickness:Â 1mm |
CVD Graphene on Silicon Substrate
| Product Name |
CVD Graphene On Silicon Substrate |
| Stock No. | NCZ-GSW-0017 |
| Purity | > 99.9% |
| Graphene Film | |
| FET Electron Mobility on Al2O3 | 2000 cm2/Vs |
| Hall Electron Mobility on SiO2/Si | Â 4000 cm2/Vs |
| Sheet Resistance |  450±40 Ω/sq (1cm x1cm) |
| Transparency | >95% |
- Copper-based graphene is prepared by CVD method.
- Graphene is transferred from copper to silicon substrate.
SILICON WAFER:
| Wafer Thickness: | 525 µm, (customization is possible) |
| Resistivity: | <0.01 ohm-cm |
| Type/Dopant: | P/N |
| Orientation: | <100> (customization is possible) |
| Front Surface: | Polished |
| Back Surface: | Etched |
CVD Graphene on SiO2 Substrate
| Product Name |
CVD Graphene on SiO2 Substrate/Wafer |
| Stock No. | NCZ-GSW-0018 |
| Purity | > 99.9% |
| Graphene Film | |
| FET Electron Mobility on Al2O3 | 2000 cm2/Vs |
| Hall Electron Mobility on SiO2/Si | Â 4000 cm2/Vs |
| Sheet Resistance | <600Ω/sq |
| Custom Order | <300Ω/sq |
| Transparency | >95% |
| CVD Graphene | Substrate |
| 1cm x 1cm | 1.5cm x 1.5cm, thickness: 300nm SiO2/700um Si |
| 1inch x 1inch | 3.0cm x 3.0cm, thickness:Â 300nm SiO2/700um Si |
| 3cm x 3cm | 3.5cm x 3.5cm, thickness:Â 300nm SiO2/700um Si |
| 7cm x 7cm | Diameter: 4inch, thickness:Â 300nm SiO2/600um Si |
Graphene Nanoplatelets Dispersion
| M | C |
| Chemical Name |
Graphene Nanoplatelets Paste and Dispersion |
| Purity | ≥99.5% |
| Diameter | 1-10 µm (Customization possible) |
| Thickness | 2-20 nm (Customization possible) |
| Number of Layers | <30 (Customization possible) |
| Color | Black |
| Form | Dispersion/Paste/Solution |
| Product Number | NCZC1009 |
| CAS Number | 7782-42-5 |
Hydroxylated Graphene Quantum Dots
Hydroxylated Graphene Quantum Dots
| CAS Number          | 7440-40-0 |
| Product Number | NCZC3002 |
| Concentration | 1mg/mL to 20 mg/mL (in stock), Concentration Customization is Possible |
| Carrier | Water, Ethanol, IPA, NMP, Toluene, Methanol, Dispersion Customization is Possible |
| APS | 5-10 nm (Customization is Possible) |
| Package Size | 1-100 mL (Customization is Possible) |
| Composition: | Hydroxylated Graphene Quantum Dots |
| Appearance: | Colorless solution |
| PL peak: | 480 nm (reference only, the actual value may vary) |
| Particle Size: | ＜10 nm |
| Concentration: | 1 mg/ml (available up to 20mg/ml) |
| Solution: | Water, a mixture of water and ethylene glycol (customization possible) |
| Purity: | > 99.9% |
