Carboxylated Graphene Quantum Dots
₹0.00
| Product Number | NCZC3003 |
| CAS Number          | 7440-40-0            |
| Concentration | 1mg/mL to 20 mg/mL (in stock), Concentration Customization is Possible |
| Carrier | Water, Ethanol, IPA, NMP, Toluene, Methanol, Dispersion Customization is Possible |
| APS | 5-10 nm (Customization is Possible) |
| Package Size | 1-100 mL (Customization is Possible) |
CHARACTERIZATIONS
| Composition: |
Carboxylated Graphene Quantum Dots |
| Appearance: | Colorless solution |
| PL peak: | 480 nm (reference only, the actual value may vary) |
| Particle Size: | ＜10 nm |
| Concentration: | 1 mg/ml (available up to 20 mg/ml) |
| Solution: | Water, Toluene (customization possible) |
| Purity: | >99.9% |
Please Note: Graphene Quantum Dots dried Powder is also available in Hydrophilic and Hydrophobic form. Please contact us for Price and other parameters customization.
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities & Customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) are available upon request.
