Copper Foil Sheets
₹0.00
Product: Copper Foil Sheets (Cu, Purity: >99.8%, APS: <20 μm)
| Materials | Copper Foil Sheets |
| Stock No. | NCZ-F-0011 |
| CAS | 7440-50-8 |
| Purity | ≥99.8% |
| APS | <20 µm, customization is available |
| Surface density | 175-181 g/m² |
| Tensile strength | ≥30 (25 °C) Kg/mm² |
| Extensibility | ≥8% |
| Roughness Rz | ≤3.0 μm |
| Thickness Tolerance | -0, 3 |
| Width Tolerance | ±1 |
| Tolerance Oxidation Susceptibility | 160°C/10 min.no oxidation |
| Polished | Single/Both Side Polished |
| Appearance Quality | No oxidation, smooth and no concave-convex |
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities & Customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) are available upon request.
