Sapphire Wafer C Plane (Al2O3)
₹0.00
Sapphire Wafer
| Product Name | Sapphire Wafer C Plane |
| Product Code | NCZ-WM-0022 |
| Cas No. | 1344-28-1 |
| Diameter | 2”, also available in 3, 5, 6, 12″ (Ask for Customization) |
| Thickness | 330 μm ± 15μm |
| Crystal Orientation | C-Plane (±0.5 Deg) |
| Surface | Single/Double Side Polished |
| Crystal | Single Crystal of Al2O3 |
| Density | 3.97 gram/cm2 |
| Crystal method | CZ |
| Carbon Contents | ≤1 ppm |
Please enquire for other wafers having different thicknesses, Diameter, Length, and sizes, etc.
If the item shown is not exactly what you require please let us know by sending us a message.
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities & Customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) are available upon request.
