Product Name: Chromium Carbide Cr3C2 Powder

Product	Chromium Carbide
Colour	Gray Powder
Purity	≥ 99.9%
Particle size	1-10 µM (customizable)
Ingredient/MF	Cr3C2
Product Code	NCZ-C-101/20
CAS Number	12012-35-0

Chromium Carbide Cr3C2 Powder APPLICATION FIELDS

Chromium Carbide Cr3C2 Powder is a ceramic compound that exists in several different chemical compositions: Cr3C2, Cr7C3, and Cr23C6. At standard conditions, it exists as a gray solid. It is extremely hard and corrosion-resistant. It is also a refractory compound, which means that it retains its strength at high temperatures as well. These properties make use as an additive to metal alloys. When chromium carbide crystals are integrated into the surface of a metal it improves the wear resistance and corrosion resistance of the metal and maintains these properties at elevated temperatures. Cr3C2 powder is mixed with solid nickel-chromium. This mixture is then heated to very high temperatures and sprayed onto the object being coated where it forms a protective layer. This layer is essentially its own metal matrix composite, consisting of hard ceramic Cr3C2 particles embedded in a nickel-chromium matrix. Cr3C2 prevents large grains from forming in the composite, which results in a fine-grained structure of superior toughness.

Chromium Carbide Cr3C2 Application:

1. Used as high temperature resistant and wear-resistant surface materials
2. Used for welding and flux-cored wire
3. Chromium carbide is useful in the surface treatment of metal components.
4. Chromium carbide is used to coat the surface of another metal in a technique known as thermal spraying.
5. Chromium carbide is used as an additive in cutting tools in order to improve toughness by preventing the growth of large grains.

Chromium Carbide Cr3C2 Properties:

There are three different crystal structures for chromium carbide corresponding to the three different chemical compositions. Cr₂₃C₆ has a cubic crystal structure and a Vickers hardness of 976 kg/mm². Cr₇C₃ has a hexagonal crystal structure and a microhardness of 1336 kg/mm². Cr₃C₂ is the most durable of the three compositions and has an orthorhombic crystal structure with a microhardness of 2280 kg/mm². For this reason, Cr₃C₂ is the primary form of chromium carbide used in surface treatment.   Please email us for the customization. Email: contact@nanochemazone.com Please contact us for customization and price inquiry Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.

Product Name: Ferrovanadium Nitride Powder

Product	Ferrovanadium Nitride Powder
Colour	Greyish silver
Purity	≥ 99.9%
Particle size	1-10 µM (customizable)
Ingredient/MF	FeVN
Product Code	NCZ-CN-149/20
CAS Number	7439-89-6 / 24646-85-3

Ferrovanadium Nitride Powder Description:

Ferrovanadium Nitride (Vanadium-Nitrogen alloy) is a composition ferrovanadium nitride. Ferrovanadium nitride is proposed for joint nitrogen and vanadium steel doping. Ferrovanadium Nitride (Vanadium-Nitrogen Alloy) is a new type of alloy additive, It can substitute Ferro Vanadium used in the production of Micro alloying-steel.

Ferrovanadium Nitride Powder Application:

1. FeVN alloy powder can be used for structural steel, tool steel, pipeline steel, steel, and cast iron.
2. It is used for nitrogen-containing steel melting: high- strength low-alloy steel (HSLA), rail steel, quick cutting steel, etc.

4. Ferrovanadium Nitride adding to the steel can increase the strength, tough, tactility, anti-thermal fatigue, etc.
5. It also can make the steel be able to fulfill solderability to attain the same strength, adding Ferrovanadium Nitride could save 30-40% of Vanadium, thereby saving the cost.

Ferrovanadium Nitride Powder Advantages:

1. Low melting point, high-density products, under the condition of the same production, vanadium and nitrogen yield is higher than similar products.
2. Low nitrogen vanadium than more reasonable, high strengthening ability.
3. Stable high product purity, ingredients, production has smaller fluctuation, the mechanical performance of steel performance has higher reliability.

Please email us for the customization. Email: contact@nanochemazone.com Please contact us for customization and price inquiry Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.

Manganese Nitride Powder

Product Name: Manganese Nitride Powder

Product	Manganese Nitride Powder
Colour	Dark Gray
Purity	≥ 99.9%
Particle size	1-10 µM (customizable)
Ingredient/MF	MnN
Product Code	NCZ-CN-148/20
CAS Number	7439-96-5

Manganese Nitride Powder Description:

Manganese Nitride Powder is generally immediately available in most volumes. High purity, submicron and nanopowder forms may be considered. Our factory produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade

Manganese Nitride in Briquettes, as a kind of Nitrogen and manganese alloy additive, its characteristics are: high content of main elements, low content of harmful impurities, Nitrogen utilization is to be improved after add melt. We adopt the continuous nitride process with unique intellectual property rights in mass production, which has stable quality and uniform nitrogen

Manganese Nitride Powder Application:

1. Used for production of special alloy steel, high strength steel, stainless steel, heat-resistant steel products

2.  Application in the field of high nitrogen steel smelting

3. Used as the steel-making additive and endow many excellent performances to steel grade such as strength, toughness, creep resistance, etc.
4. Specialty demonstrated its good market prospects in large diameter steel pipe of transmitting oil and gas strength steel in shipbuilding and automotive.

Basic information of Manganese Nitride Powder

Manganese (atomic symbol: Mn, atomic number: 25) is a Block D, Group 7, Period 4 element with an atomic weight of 54.938045.

In its elemental form, manganese has a silvery metallic appearance.

It is a paramagnetic metal that oxidizes easily in addition to being very hard and brittle.

Manganese is found as a free element in nature and also in the minerals pyrolusite, braunite, psilomelane, and rhodochrosite.

Nitrogen is a Block P, Group 15, Period 2 element.

Nitrogen is an odorless, tasteless, colorless, and mostly inert gas.

It is the seventh most abundant element in the universe, and it constitutes 78.09% (by volume) of Earth’s atmosphere.

Please email us for the customization. Email: contact@nanochemazone.com Please contact us for customization and price inquiry Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.

Titanium Carbide Powder

Product Name: Titanium Carbide Powder

Product	Titanium Carbide Powder
Colour	Grey
Purity	≥ 99.9%
Particle size	1-10 µM (customizable)
Ingredient/MF	TiC
Product Code	NCZ-C-106/20
CAS Number	12070-08-5

Titanium Carbide Powder Description :

Titanium Carbide (TIC) is a Gray metallic powder with a cubic system structure. With high-wear resistance, perfect corrosion resistance and high-temperature resistance, As hardness material, it’s widely used as the thermal spray coating powder material, the welding material, the flinty membranous material, the military aviation material, the hard alloy, and the cermet. Titanium carbide, TiC, is an extremely hard (Mohs 9-9.5) refractory ceramic material, similar to tungsten carbide. It has the appearance of black powder with the sodium chloride (face-centered cubic) crystal structure. Also, the product has good conductivity and chemical inert ability to steel and iron

Application of Titanium Carbide TiC:

1. The carbide is mainly used in the manufacturing of cermet, heat-resistant alloy, and cemented carbide due to its high melting point, high hardness, and good chemical stability.

2. Applies in the spray coating material, the welding material, the flinty membranous material, the military aviation material, the hard alloy, and the cermet.

3.Used as welding and flux-cored wire

4. Used in the preparation of cermets, which are frequently used to machine steel materials at high cutting speed.
5. Used as an abrasion-resistant surface coating on metal parts, such as tool bits and watch mechanisms.
6. Used as a heat shield coating for atmospheric reentry of spacecraft.

7. TiC is used in manufacturing wear-resistant materials, cutting tools, etc Please email us for the customization. Email: contact@nanochemazone.com Please contact us for customization and price inquiry Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
