Nickel Foil
₹0.00
Product: Nickel Foil (Ni, Purity: 99.9%, Thickness: 12 µm)
| Materials | Nickel Foil |
| Stock No. | NCZ-F-0015 |
| CAS | 7440-02-0 |
| Purity | ≥ 99.9% |
| Thickness | 12 μm, customization is available |
| Width | 30~500 mm, customization is available |
| Surface density | 8.908Â g/cm3 |
| Melting Point | 1455 °C |
| Boiling Point | 2730 °C |
| Joint | 1pcs/roll |
| Polished | One/Both Side Polished |
| Polished | One Side Coarse |
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities & Customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) are available upon request.
Shipping & Delivery
Related products
Aluminum Metal Foam
Aluminium Metal Foams
Product: Aluminium Metal Foam (Closed Cell or Open Cell, 2-11 mm)
| Stock No. | NCZFF108 |
| Density | 0.1 to 0.35 g/cm³ |
| Pore Size | 2-11 mm, 5 mm (Closed Cell as well as Open Cell) |
| Porosity | 60-90%, customization is also possible |
| Compressive Strength | 44 Mpa |
| Blending Strength | 27 Mpa |
| Acoustic Absorptive | 0.48 |
| Foam Size | 100 x 100 x 5 mm, customization is also possible |
Physical Characteristics Aluminium Metal Foam
| Heat Resistivity | 660 °C |
| Acoustic Frequency | Between 125 and 2000 HZ |
| Noise Reduction Coefficient | >0.4 |
| Thermal Insulation Properties | About 1 / 400 of metal Aluminium |
| Electromagnetic Wave Frequency | Between 2.6 and 18 GHZ |
| Electromagnetic Shielding Property | Up to 60 – 90 dB |
| Resistivity | 100 Times Over Metal Aluminium |
Aluminium Metal Foam Open Cell or Closed Cell, Both are Available (Ask for Customization)
Copper Foil Sheets
Product: Copper Foil Sheets (Cu, Purity: >99.8%, APS: <20 μm)
| Materials | Copper Foil Sheets |
| Stock No. | NCZ-F-0011 |
| CAS | 7440-50-8 |
| Purity | ≥99.8% |
| APS | <20 µm, customization is available |
| Surface density | 175-181 g/m² |
| Tensile strength | ≥30 (25 °C) Kg/mm² |
| Extensibility | ≥8% |
| Roughness Rz | ≤3.0 μm |
| Thickness Tolerance | -0, 3 |
| Width Tolerance | ±1 |
| Tolerance Oxidation Susceptibility | 160°C/10 min.no oxidation |
| Polished | Single/Both Side Polished |
| Appearance Quality | No oxidation, smooth and no concave-convex |
Electrical Conductive Nickel Metal Foam
Nickel Metal Foam
| Product Name | Nickel Metal Foam |
| Stock No | NCZFF104 |
| CAS | 7440-02-0 |
| Purity | > 99.9% |
| PPI | 10-95, customization is available |
| Pore Size | 00.5-0.5 mm, customization is available |
| Length | 500 mm, customization is available |
| Width | 500 mm, customization is available |
| Thickness | 1-20 mm, customization is available |
| Porosity | ≥ 95%, customization is available |
| Molecular Formula | Ni |
| Molecular Weight | 58.71 g/mol |
| Melting Point | 1453 °C |
| Boiling Point | 2730 °C |
| Density | 8.90 g/cm³ |
| Surface Density | 346g/m^2 |
Nickel Foam is available in a closed cell as well as open cell, please ask for customization while ordering.
Palladium Metal Foil
Product: Palladium Metal Foil (Pd, Purity: 99.9%, Thickness: 12 µm)
| Materials | Palladium Metal Foil |
| Stock No. | NCZ-F-0016 |
| CAS | 7440-05-3 |
| Purity | ≥ 99.9% |
| Thickness | 12 μm, customization is possible |
| Width | 30~500 mm, customization is possible |
| Surface density | 12.023Â g/cm3 |
| Melting Point | 1554 °C |
| Boiling Point | 2963 °C |
| Joint | 1pcs/roll |
| Polished | One / Both Side Polished |
| Polished | One Side Coarse |
Platinum Foil Sheets
Platinum Foil Sheets (Pt foil, thickness 0.1 mm, ≥99.99% trace metals basis)
Platinum Foil SheetsProduct: Platinum Foil Sheets (Pt foil, thickness 0.1 mm, ≥99.99% trace metals basis)
| Molecular Formula | Pt |
| Appearance | Solid Foil |
| CAS No. | 7440-06-4 |
| Stock No. | NCZ-F-0012 |
| Molecular Weight | 195.08 |
| Assay | ≥99.99% trace metals basis |
| Density | 21.45 g/cm3 |
| Melting Point | 1772 °C |
| Boiling Point | 3827  °C |
| Storage & Sensitivity | Ambient temperatures |
| Resistivity | 10.6 μΩ-cm, 20°C |
| Young's Modulus | 168 GPa |
| Size | 25 × 25 mm; 50 × 50 mm, 100 x 100 mm (Customization is available on request) |
| Thickness | 0.025 mm, 0.05 mm, 0.1 mm, 0.25 mm, 0.5 mm, 1 mm etc. (Customization is available on request) |
Premium Grade Copper Metal Foams
Product: Copper Foam (Cu Foam, Purity: 99.9%, 50PPI/1mm)
Copper Metal Foams
| Stock No. | NCZFF102 |
| PPI | 10 to 110, customization is also possible |
| Bulk Density | 0.80-0.85 g/cc |
| Purity | ≥99.9% |
| Porosity | ≥70% , customization is also possible |
| Dimension | 500 mm X 500 mm, customization is also possible |
| Thickness | 1mm to 25mm, customization is also possible |
| Compression Strength | 131 psi |
| Tensile Strength | 1000 psi |
| Shear Strength | 190 psi |
| Modulus of Elasticity (Compression) | 107 kpsi |
| Modulus of Elasticity (Tension) | 14.6 × 103 psi |
| Shear Modulus | 40.9 kpsi |
| Vickers Hardness | 35 |
| Specific Heat | 0.385 J/g-°C |
| Bulk Thermal Conductivity | 10.1 W/m-°C |
| Coefficient of Thermal Expansion | 1.7 × 10-5 m/m–°C (0-100°C) |
| Bulk Resistivity | 2.56× 10-5 ohm – in |
| Melting Point | 1080 °C |
Silver Foil Sheets
Silver Foil Sheets (Ag foil, thickness 0.025 mm, ≥ 99.99% trace metals basis)
Silver Foil Sheets
Product: Silver Foil Sheets (Ag foil, thickness 0.025 mm, ≥ 99.99% trace metals basis)Â
| Materials | Silver Foil Sheets |
| Chemical Formula | Ag |
| Stock No. | NCZ-F-00117 |
| CAS | 7440-22-4 |
| Purity | ≥ 99.9% |
| Thickness | 0.025 mm, 0.05 mm, 0.1 mm, 0.25 mm, 0.5 mm, 1 mm etc. (Customization is available on request) |
| Molecular Weight | 107.87 |
| EC Number | 231-131-3 |
| PubChem Substance ID | 24856080 |
| Density | 10.49 g/cm3(lit.) |
| Resistivity | 1.59 μΩ-cm, 20°C |
| Boiling Point | 2212 °C(lit.) |
| Melting Point | 960 °C(lit.) |
| Polished | Both Side Polished, one side polished, without Polish (Customization possible) |
| Appearance Quality | Foil/Sheet appearance |
| Size | 25 × 25 mm, 25 x 50 mm, 50 × 50 mm, 100 x 100 mm (Customization is available on request) |
